Infusion Pump

Design that is both lightweight and compact.Easy-to-operate soft key. Top indicator light.

Directly load the volume and rate of the most recent infusion.

Volume-adjustable buzzer.Three occlusion pressure settings that are adjustable.

Protection against free flow.Panel lock.

A double CPU guarantees secure infusion.Pump body that is easily removable for convenienceinput:
output:
Functions and Featuresinput:
output:Rate mode - Infusion mode

Flow rate range -- 0.1 to 1200 ml/h, Micro mode: 0.1 to 99.9 ml/h in 0.1 ml increments, 1-400 drops/min00h:00m remains The flow rate and VTBI setting are the determining factors.

Volume to be infused (VTBI) - 0 to 9999 mlVolume Infused (Σ) - 0 ~ 36,000 mlKVO rate: 1-5 ml

Accuracy of infusion - ±5%

Purge at a rate of 600 ml/h.Bolus rate: 300-1200 ml/hA wide variety of infusion set brands are applicable.Air bubble detection - Ultrasound sensor detection with four adjustable air in line alarm levels

Occlusion pressure - Three adjustable occlusion pressure settings: low, middle, and high.Alarms - Visual and audible alarms, including door open, air-in-line, occlusion, infusion completion, low battery, battery depletion, and malfunction.Battery: 7.4V, 2100mAh rechargeable lithium polymer battery. Operates for over three hours at a rate of 25 milliliters per hour when fully charged.Battery recharge time -- 10 hours with power on, 3 hours with power offDC: 12V ±1V, AC: 100~240V, 50/60Hz

Classification - Type CF Px3, Class l
