In-Line Thermoformer

Model MP400 thermoforming machine (applications: industrial blister packaging, medical and pharmaceutical products)input:
output:Machine frame length -2.5 meters and 3 metersinput:
output:Welding protection -Standard in length; cannot be lifted in plexiinput:
output:Standard width (mm): 320 or 420input:
output:Minimum and maximum widths (mm) that can be adjusted – 220 and 420 (optional)input:
output:Maximum depth of suppleness (mm) – 70 / 110input:
output:Maximum depth of stiffness (mm) – 50. One deposit.The maximum pitch is as follows:300 on the 3 meter and 240 on the 2.5 meterLower supply diameter: 400 mm aluminuminput:
output:Upper supply diameter:

Aluminum with a diameter of 300 millimeterinput:
output:Utilization of rigid films -maximum: 600 µMinimum/maximum speed of supple film (strokes per minute) -6 to 12 strokes per minuteinput:
output:Minimum and maximum pace of stiff film (strokes per minute) -5 to 8 strokes per minuteinput:
output:Length -3.5 meters to 4 metersWidth: 1.1 metersHeight: 1.8 metersConsumption of water -200 liters per hour Electricity consumption: 6 kilowattsAir consumption -36-40 Nm3 per hour
