Image Interpretation Module

A single PCBA contains a photodiode, ADC, FPGA, and scintillator.

High-light-output, ultra-fast medical-grade GOS scintillatorFSI photodiode with ultra-low dark current and high sensitivity

24-bit ADC with low noise and high resolution

The integration time can be adjusted from 100 μs to 100 ms.Sampling without loss of charge20 mm of anatomical coverage at the isocenterLVDS digital interfaceFull-scale range that can be adjusted: 6.25 to 150 pCinput:
output:A standard detector solution that is specifically designed to meet the requirements of medical CT imaging in the value segment is the X-ACE 16 HD. Alternatively, the plug-and-play solution is available as a complete subsystem that includes detector modules, X-DCB2 data combiner board and adapter, software libraries, and all necessary accessories, or as 16-slice detector cards. The X-ACE 16 HD, which is investment-free, expedites the time-to-market of CT systems in the highly competitive medical imaging market and results in substantial total cost savings.input:
output:The X-ACE product family is constructed on a modular and well-established platform. The platform boasts the highest level of integration and covers a wide imaging area. This is achieved by assembling a scintillator, a photodiode, analog-to-digital converters (ADC), and a fieldprogrammable gate array (FPGA) onto a single printed circuit board (PCB). This results in a streamlined supply chain, simplified system designs, straightforward integration, minimized risks, and detector solutions that are mechanically more robust and digitally enhanced.
