Hydrogen Analyzer

The 5E Series C/H/N Elemental Analyzer is frequently employed in a variety of industries, including power plants, coal mines, metallurgy, chemical industry, commercial inspection, scientific research, food industry, and education, to ascertain the carbon, hydrogen, and nitrogen contents of solid and liquid materials, including coal, coke, oil, petroleum, biomass, fertilizer, plastic, food, hydrocarbons, plant tissue, leaves, and tobacco.input:
output:Characteristics:Maximum Efficiency

1. High throughput: standard auto loader with a capacity of 35 samples per layer, stackable up to four layers.

2. A dual-stage furnace system that utilizes pure oxygen flow to guarantee the complete combustion of all samples.input:
output:Adaptability to a favorable environment input:
output:1. The system's gas tightness is ensured by the optimal gas circuit.

2. O-rings that are not subject to heat resources. Minimum Consumption:1. Separate detectors to ascertain C, H, and N, respectively. The software allows for the selection of CH mode and CHN mode analysis. (For 5E-CHN2200)

2. Time, gas, and reagent savings: The analysis required only 5.5 ml of blended gas.Unattended Operationinput:
output:The operator's capabilities are restricted to the addition of samples to the auto sample loader. Subsequently, the instrument will conclude the examination, cool down, and shut down automatically.input:
output:Computer Standard Configuration:PrinterMain analyzer

Reagent for the furnace

High-purity copperN-CatalystStandard Reference Material (GBW) H2O sorb reagentinput:
output:AR427 com-aid for liquid sample is an optional configuration.

An additional two carousels with four layers are included.

Tin-foil cup with a size of 4cm x 4cm

Specifications: Larger-sized hole carouselinput:
output:Conforms to the following methods: AS 1038.6.4, ASTM D5373, ASTM D5291, ISO 16634, ISO 16948, ISO 29541, EN 15407, EN ISO 16948:2015-0, GB/T 30728, GB/T 30733, UNI 15104, UNI CEN/TS 15407.
