Hplc Chromatography Detector

The Sykam S 3245 UV/Vis Detector is well-suited for both routine and advanced research applications due to its high sensitivity, stable baseline, and low drift signal.input:
output:Summaryinput:
output:Built around a high-quality "moving monochromator" optics, the Sykam S 3245 UV/Vis Detector is a single or dual channel variable wavelength detector with a wavelength range of 190 to 900 nm. This design ensures that light energy is lost at a minimum at any selected wavelength. The S 3245 is a UV/Vis detector that is suitable for both routine and advanced research applications due to its high sensitivity, stable baseline, and low drift signal.input:
output:The free programming of various wavelengths within a run is facilitated by an integrated wavelength program. A unique feature of the S 3245 is the integrated peak detector, which enables direct control of external solenoid valves through a programmable delay function on an integrated 24-volt output stage. The addition of a low-pressure three-way valve enables the simple collection of fractions or the recycling of solvents.input:
output:Technical Specificationsinput:
output:Dimensions: 47.8 × 31 × 16.5 cminput:
output:Detector -Single channel, dual channel (optional)The wavelength range is 190–900 nm.input:
output:Optical bandwidth: 5 nminput:
output:Wavelength programming -A maximum of 10 wavelengths are permitted per analysis.input:
output:Accessible without the need to remove covers-

Column connection and flow cell located at the front for convenient accessinput:
output:Peak detector

-

Integratedoutput stage

-

24 volt valve controlIn-line fast wavelength scanning -OptionalFlow cell -analytical stainless steel, analytical PEEK, micro stainless steel, micro PEEK, preparative stainless steel, and preparative PEEK
