Hot Water Boiler

The GEOTHERM ® WGB (P) series boilers are engineered to generate hot water. The primary objective of boilers is to supply heat to domestic and industrial facilities.input:
output:There are three temperature schedules for the GEOTHERM ® WGB (P) series boilers: 70-95 °C, 70-110 °C, and 70-150 °C.input:
output:The GEOTHERM ® VWS (P) series boilers are manufactured with a capacity ranging from 0.63 to 58.2 MW.

The primary distinction between the boilers of the GEOTHERM ® WB (P) series and the boilers of the GEOTHERM WEB(3P), GEOTHERM WEB, and GEOTHERM WEB(V) series is that the exhaust gases are immediately directed through the convective surface following the combustion of the burner’s torch.input:
output:
The collector frame is responsible for the distribution of water flows in accordance with the hydraulic circuit of the boiler and the connection of the boiler to the external strapping.input:
output:The boiler pipe system is primarily composed of the convective section.input:
output:The boiler pipe system is installed on the support frame, which functions as the foundation.input:
output:The boiler’s rigidity is guaranteed by the stiffness belt, which functions as a frame.input:
output:The flue duct, which is equipped with an explosive valve, functions as a conduit for the discharge of exhaust gases. input:
output:The fuel’s complete combustion is guaranteed by the increased volume of the combustion chamber. The temperature of flue gases emanating from the boiler is decreased by the convective surface of u-shaped pipes. High-quality thermal insulation reduces heat loss through the boiler walls.input:
output:It prevents the entry of air into the boiler furnace and enables the use of light thermal insulation that is up to 50 mm thick. With a decorative lining.
