Histopathology Laboratory Workstation

A down-draft grossing table is equipped with an air-down draft system. The laboratory environment is guaranteed to be free of pollutants while slicing and preparing histological slide preparations on this specialized work table, which is also well-suited for small dissections. The removal of unsanitary vapors is optimized by the airflow that travels over the entire working area and is vacuumed out underneath. The entire Vacuum-effected area has MAC (maximum allowable concentration) values for formalin that are below the target. A side-mounted exhaust system that the customer has provided is to be connected to the cutting table.



The following features are included in the UCS models:

Dual workplace

Workstations with a substantial surface area
The entire structure is composed of stainless steel.

Adjustable legs and a self-supporting, stable undercarriageThe upper structure's low overall height enhances leg room.The work surface is comprised of a basin that is seamlessly welded and measures 400 x 400 x 200 mm.The basin is equipped with an integrated air vacuum.

The basin may be installed on either the right or left side.Very durable, perforated, and insertable working plates

Under the perforated working plates, there is an integrated sprinkler system with an adjustable valve for bath sanitation.Formalin sink with sieve insertMixing tap with detachable cold and hot water shower Exhaust duct on the left or right sideTECHNICAL DATADimensions: 1500 x 1000 x 750 mm Width x depth x heightCapacity of exhaust air:A minimum of 1000 m³/h is required.Material:brushed stainless steel (1.4301 - ANSI 304)input:
output:Perforated working area: approximately 960 x 920 mmCold/warm water connection: 1/2" Waste water connection: 2"Diameter of exhaust duct: 250 mm
