Heating Furnace
Reference: 906027
Dental Laboratory
| Type | Vacuum |
| Applications | For Dental Laboratories |
| Designed For | For Metal, Ceramic |
| Function | Heating |
| Other Characteristics | High-Performance, Automatic |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
Automatic programmable dental furnace for pure ceramics and metals. Designed to accommodate all available dental metal ceramics. Includes 255 individual programs.The process is entirely controlled, with 16 programmable parameters in each program. Additionally, the system of self-diagnostics and auto calibration has been enhanced.7 TFT display with protective tempered glassSensor buttons
graphical representation of process progression
a quartz spiral tube-based heater that is equipped with a heating elementPt/Ro thermocapleThe program will be automatically resumed following a brief power outage.USB transfer of program parameters remote damage analysisinput:
output:Accessories: isolation table Ref. № 122000025
firing tray pinsTECHNICAL DATA br/>
Vacuum pump PVM122 Ref. № 032000000Power supply: Approximately 230 volts with a tolerance of ±10%, operating at 50/60 Hz.Power consumption -Furnace with vacuum pump - 1700 wattsFurnace without vacuum pump: 1550 watts
Vacuum pump data -Vacuum that can be adjusted from 0.1 to 0.92 bar
The dimensions of the firing chamber are as follows: a diameter of 95 mm and altitude of 60 mm.Dimensions (W/D/H): 265/370/565 mmWeight: 25 kilograms
graphical representation of process progression
a quartz spiral tube-based heater that is equipped with a heating elementPt/Ro thermocapleThe program will be automatically resumed following a brief power outage.USB transfer of program parameters remote damage analysisinput:
output:Accessories: isolation table Ref. № 122000025
firing tray pinsTECHNICAL DATA br/>
Vacuum pump PVM122 Ref. № 032000000Power supply: Approximately 230 volts with a tolerance of ±10%, operating at 50/60 Hz.Power consumption -Furnace with vacuum pump - 1700 wattsFurnace without vacuum pump: 1550 watts
Vacuum pump data -Vacuum that can be adjusted from 0.1 to 0.92 bar
The dimensions of the firing chamber are as follows: a diameter of 95 mm and altitude of 60 mm.Dimensions (W/D/H): 265/370/565 mmWeight: 25 kilograms
