Heating Furnace

• Maximum energy savings are achieved through the use of high-purity fibrous alumina insulation.• The furnace’s exteriors are kept safe to touch by a double-layered steel structure equipped with an air cooling fan.• Safety interlock that automatically turns off the furnace when the door is opened (optional)• The resistor is fired by the current limiting phase angle in PID automatic control, such as the SC R (Silicon Controlled Rectifier).• Programmable power control with 30 segments.input:
output:Accessories (please indicate these at the time of ordering)1 Traditional Accessoriesinput:
output:Thermal gloves | Crucible tongs | Thermocouple | Furnace Door Block | User Manualinput:
output:2. Optionalinput:
output:A variety of chamber sizes are available for your selection.Touch screen (with USB interface)Control equipment and computer connection software (RKC, 16-segment program, interface, and software)

Note: You are limited to selecting one option from the options between 2 and 3.Detailsinput:
output:Continuous working temperature: ≤1100℃

Resistance wire with Mo heating element

K-type thermal couple

Composition of the chamber Alumina polycrystalline fiber of exceptional purity

The recommended heating rate is 15℃/min, with a range of 0 to 30℃/min.±1℃ thermal control accuracy

±5℃ temperature uniformity

AC 100V-415V, 50Hz/60Hz power supplyinput:
output:Please be advised that:The rate of heat up is determined by employing an empty chamber.

A continuous operating temperature is used to measure holding power.
