Handheld Patient Monitor

Application:Pet medical care: It can assist veterinarians in the timely comprehension of the respiratory status and ventilation conditions of pets, as well as in the monitoring of their physiological parameters.input:
output:Characteristics:1. Measure ETCO2, FiCO2, RR, SPO2, and PR with precision.

2. The device is capable of being used in plateau environments and helicopter rescues, and it is equipped with an automatic compensation system for atmospheric pressure and body temperature and pulmonary pressure (BTPS). Zero calibration necessitates no manual intervention.

The 3.2.8-inch touch button operation is user-friendly, lightweight, and features an adjustable alarm volume, making it convenient to monitor and transport.

4. The patented filter is safeguarded from moisture, secretions, bacteria, and dust. It is capable of operating continuously in a humid environment and has a substantial water storage capacity, as well as a small dead space.

5. Various data output modes: real-time and historical data can be uploaded to a PC via USB, and real-time data can be transmitted to a mobile data terminal via Bluetooth.

6. A 24-hour trend chart that is compatible with PC database management software is available for the purpose of printing comprehensive reports and trend data.

7. Supports eight languages.

8. Offer a diverse selection of blood oxygen probes that are appropriate for animals, including finger clips, ear clips, and tail clips.

Data Measurement with a CapnographEtCO2/CO2

Range: 0-150mmHg (or 0-20kPa or 0-20% V/V)

Precision:±2mmHg when the range is 0-40mmHg,
±5% (reading) when the blood pressure exceeds 41-70 mmHg

±8% (reading) when the blood pressure exceeds 71-100mmHg

±10% (reading) when the blood pressure is between 101 and 150 mmHg

etCO2 Update: The user has the option to select a duration of 10, 20, or 30 seconds for each breath.

The duration of the trend is 24 hours.Rate of respiration

The range is from 3 to 150 t/min.Accuracy: the greater value of ±1% (reading) or ±1 times/min

Duration of the trend: twenty-four hoursSelectable flux: 50-250 cc/min
