Hand-Held Pulse Oximeter

Acquisition that is straightforward and rapid

A 3.5-inch color LCD monitor that provides a clear view

Large memory: up to 30 days in 10 seconds Perfusion index indication User-friendly interface

SpO2, BPM, and pulse parameter display Intuitive operation Vertical and horizontal display of measurement valueinput:
output:Description

Overview

3.5-inch LCD with waveform and numeric displayImproved memory capacity: up to 30 days in a 10-second interval

Arrangement in a vertical

Indication of perfusion index

IV-pole mounting with pole clamp holder

Specification

Dimensions: 75 x 210 x 45 mmWeight: approximately 0.3 kilogramsAdapter 5V, 2.0 A, Power AC 100-240V (50/60Hz)24VA (maximum) power consumptionA 3.5″ color TFT-LCD screen is displayed.The resolution is 320 x 480 pixels.The following data is displayed: SpO₂, Pulse rate, Perfusion index, Level Bar, Pulse rate Wave, Time and Date, Alarm Volume, Battery Status, and Brightness.LED indicators Sensor Separation, Alarm Silence, Charging Status, and Power Connection

SpO2, pulse rate, and PI (Perfusion Index) are the parameters.Interfaces – DC input connector: 5V, 2.0AUSB digital output for data transferSpO2 and pulse rate data storage (30 days at 10-second intervals)Storage: –20 ~ +70 °C Temperature Operation: 5 ~ +40 °CHumidity Operation: 30% to 85%, Storage: 5% to 95% (Package)AltitudeOperation: 525 ~ 795 mmHg (70 ~ 106 kPa) Storage: 375 ~ 795 mmHg (50 ~ 106 kPa)Accuracy of pulse rate within ±2 bpm
