General Care Training Manikin

Annequin resembles a typical animal by producing CO2 at a consistent rate, which must be eliminated through ventilation.input:
output:A novel dummy animal, the Annequin (animal mannequin), is capable of precisely replicating the behavior and responses observed in ventilated animals in terms of CO2 elimination.


The Annequin kit is compatible with all standard ventilators and capnographs. Annequin reproduces the behavior of a typical animal by producing CO2 at a consistent rate, which must be eliminated through ventilation. Nevertheless, it is necessary to provide the Annequin with a feed of 100% CO2. This gas is typically readily accessible in clinical settings, as it is employed for insufflation during laporoscopies. A precision low flow (0-100ml) flow meter is included in our kit to enable you to precisely regulate the CO2 flow into your annequin.



The effects of over and under-ventilation, as well as the effects of dead space and flow rates in breathing circuits, can be easily simulated with Annequin. Additionally, the effects of hyper and hypocapnic states can be investigated.

This enables the safe practical training of veterinarians and nurses in the response to ventilation emergencies.

The annequins that are supplied have a compliance of approximately 15 mls/cm and a typical tidal volume of 150-200 mls.input:
output:The Annequin kit (VS0800) comprises the following:input:
output:• One single Annequin with a CO2 feed portal, oral 15mm ET connector, and "lung"• 2732 – 1 x 2.45m CO2 feed line with male-male luer connections

• VS0750 – 1 x 0-100ml/min CO2 flow meter on a stand• VS0760 – One Luer-Luer stopcock• VS0765 – 1 x 2m length 4mm polyethylene tubing with 1 x male luer connector
