Gel Documentation System Transilluminator

Multi-wavelength transilluminators (UV, white, and blue light)Filter sizes range from 15 x 15 cm to 25 x 26 cm or 20 x 40 cm.

Illumination that is exceptionally consistent

High-quality filter glass to reduce background noise

A diverse selection of high-performance and standard modelsinput:
output:Details of the ProductUV transilluminators for UV fluorescent stainsinput:
output:UVP UV Transilluminators provide a bright and uniform illumination. A low background signal is achieved through the exclusive use of high-grade filter glass, resulting in exceptional documentation results. The reliable quantification of fluorescent samples that have been electrophoretically separated is facilitated by the exceptional uniformity of illumination.input:
output:UVP Transilluminators are designed to protect the user from ultraviolet radiation by incorporating an ultraviolet blocking cover. The base is equipped with a scratch-resistant, high-quality powder coat. Powder coat paint or a stainless steel top assembly are included in the models.input:
output:UVP Benchtop UV TransilluminatorsAll UVP Benchtop Transilluminators are lightweight and compact. Benchtop models are offered in four distinct UV illumination configurations: a Single UV with optional variable intensity (302 nm), 2UV (302 and 365 nm or 254 and 365 nm), and 3UV (254, 302, and 365 nm). Various filter sizes are accessible and can be viewed in the Order Information section below.input:
output:Features of the variable intensity models include:input:
output:High-level setting for UV excitation of fluorophores on gels for routine photography. Additionally, gels with low sample concentrations are stimulated.

Medium intensity for viewing and rapid single-band excision.

Low setting for positioning and preparing the gel, focusing for photography, and excising multiple bands.
