Fully Automated Elisa Workstation

LB-10 ELISA workstationELISA is a multifunctional liquid handling system that is a fully automated immunoassay processor. It is distinguished by the distinctive module layout that incorporates pipetting, washing, incubating, and reader functions. Disposable tips are included in the dispense channels to prevent contamination. Dispensing-aspirating washing mode is implemented at the workstation.input:
output:Characteristicsinput:
output:Module for photometric microplate readinginput:
output:
Pipetting system that utilizes air displacementinput:
output:
Crosswise aspiration with adjustable injection heightinput:
output:Monitoring of liquid levels, clots, and empty tubes



Manual barcode scanning is an optional feature.input:
output:Multifunctional liquid handling (dilution, conjugation, aliquoting)Dispensing that is both diverse and numerousApplications br/>



Detects antigens or antibodies in serum, sputum, semen, urine, stool, and culture supernatant in the fields of microbiology, genetic profiling, biotechnology, biochemistry, zoology, and clinical trials.input:
output:Detailsinput:
output:Benchtop Assemblyinput:
output:Total number of channels: 2input:
output:Disposable tips are available in two sizes: 300 µL and 800 µL.Pipetting range: 1 µL to 1000 µLPipetting increment -- 0.1 µLPipetting precision and accuracy (300 µL and 800 µL) - Volume: 100 µLinput:
output:Precision: ± 1%input:
output:Precision: less than 0.75 percentinput:
output:12 rails in totalinput:
output:144 control positions - 6 × 24input:
output:Positions of reagents - 6 multiplied by 4 equals 24.input:
output:Plate positions: 4 + 1 ambient (optional)Temperature range: RT to 60°Cinput:
output:Temperature increase–0.1°Cinput:
output:Accuracy of temperature - ± 0.5 °CWashing channels: 1 x 8Three wash buffers are available for selection.Wash volume: 50 µL to 1000 µL per well.Residual volume: ≤ 2 µL per well.Interface: RS232 and USBinput:
output:Specifications: 1270 × 785 × 1000 mm in sizeWeight: 180 kilograms
