Forced Convection Laboratory Incubator

Residence

Epoxy-resin-coated galvanized steel sheet, RAL 7035. Lockable unit on four castors.input:
output:Interior area

Constructed from premium stainless steel. The interior features a slippery surface and rounded corners, which make it easy to clean and meet the most stringent hygiene standards.

The thermo-jacket circulation system guarantees that the samples are not dried and that the temperature and humidity levels are distributed evenly within the chamber. There is an airflow that occurs outside of the workspace. The circulation fan ceases to operate approximately 40 seconds after the door is opened, despite the fact that the internal temperature is comparable to the prevailing outdoor temperature. The inner casing is merely removed to facilitate a thorough cleaning.input:
output:Door

A double-walled insulation door that is hinged on the right-hand side. An all-purpose sealing strip that is magnetic and resistant to laboratory cleaning agents.input:
output:Optional:

accompanied by a door lock Triple-glazed inspection window with a cover located in the front door

Dimensions: 32 cm in width and 77 cm in height – refer to image.Fittings for the interior

3 perforated stainless steel shelves are included in the standard configuration, with a maximum of 14. The maximum load per shelf is 20 kg in the event of a constant distribution, resulting in a total load of 120 kg. The dimensions of the shelf are as follows: W = 500 mm, D = 450 mm.Instrument and control panel,incl. temperature controller with digital indication, situated above the door

Microprocessor-controller

featuring a digital LCD display. The temperature and time are entered using a membrane keypad that is visible on the LCD display.With an RS-232C serial interface. Minutes can be specified in the range of 1 to 999.input:
output:The actual operating time is consistent with the set time. Consequently, it is unnecessary to estimate and incorporate the heating time. input:
output:Accuracy of temperature: temporal: +/-0.2°C, spatial: +/-0.3°C
