Fluoroscopy Test Phantom

The imaging performance of digital fluoroscopic systems is assessed daily using this routine medical imaging test phantom, which is both efficient and straightforward to operate. The grey-scale can be verified, the number of contrast details can be counted, and the line patterns can be resolved. This may suggest that the image quality of your fluoroscopic imaging system is deteriorating if these numbers ever deviate from the norm.input:
output:It enables the assessment of:
Adjustment of brightness and contrast: Pb is used for low-light details, while Cu is used for high-light conditions.

Scanning linearity: geometry assessment

Contrast in imaging: 1mm Cu, 8mm diameter, 18 low-contrast and high-contrast details with contrast values ranging from 0.9 to 16.7% @70kVp.

Resolution: 0.5 to 5.0 line pairs per millimeter

Markings for geometry and collimation verificationinput:
output:Description:Dimensions: 220 x 190mm

Ten millimeters in thickness

Upon request, variable designs with varying FOV sizes are available.input:
output:Is supplied with:High purity, 1 mm A copper attenuation filter is required for installation in the diaphragm housing.User manual that is comprehensiveA durable carrying case that facilitates transportationinput:
output:Is in accordance with:IEC 61223-3-1

The Institute of Physics and Engineering in Medicine published IPEM Report 91 (2005), which outlines the recommended standards for the routine performance testing of diagnostic X-ray imaging systems.
