Fluorescent Podoscope

The Plantograph PL-1M is employed in diagnostic offices, medical centers, and other medical and preventive facilities to conduct visual screening analyses of the human musculoskeletal system, diagnose and monitor orthopedic diseases and foot deformities in both children and adults, and to select and manufacture insoles (ortheses) and shoes.input:
output:
The plantograph is equipped with a mirror that is mounted at an angle to the support plate and a horizontal support plate that is specifically designed to accommodate the patient's feet. Rubber seals are employed to guarantee dependable fixation during diagnostics, and the support plate and mirror are situated on a fully welded metal frame.input:
output:
The plantograph's overall dimensions are 520*585*310 mm (L*W*H).

The platform for the feet measures 420*470 in terms of length and width.input:
output:The mirror's angle of inclination is 15°.input:
output:The chair's dimensions are 640 x 400 x 675.input:
output:Voltage of the power supply, V, is 220±10%.input:
output:50 Hz frequencyinput:
output:15 watts of power consumptioninput:
output:
The maximum permissible load on the working surface is 120 kg.input:
output:Note: The functionality and purpose of the product are not impacted by the slight deviations in the dimensions, which may occur depending on the production batch.
