Fluorescence Immunoassay Poc Analyzer

This instrument is exclusively intended for in vitro diagnostic purposes. Proficient laboratory environments within medical institutions, including central laboratories, emergency departments, clinical units, and health assessment centers, are the intended recipients. input:
output:TESTING PRINCIPLEinput:
output:The excitation light source for the Medlere Fluorescence Immuno-analyzer is an LED. The electrical signal is generated by the collection and conversion of the emitted light from the fluorescence microspheres. The quantity of fluorescence dye molecules present on the examination site is closely correlated with the signals. A pre-programmed calibration process is used to determine the concentration of the analyte after a sample is applied to the test cartridge. The Medlere Fluorescence Immuno-analyzer is exclusively capable of accepting test cartridges that are supplied by Medlere Limited.Technical Parameters



Parameters


Dimensions: 240mm x 214mm x 120mminput:
output:1.5 kg±300mg in weightinput:
output:Power Conditions DC12V, 5Ainput:
output:Repeatability CV: 1% Stability CV: 1%Operating Environmentinput:
output:Temperature range: 5 to 40 degrees Celsiusinput:
output:Humidity Ratio ten to eighty percentinput:
output:860 to 1060 hPa atmospheric pressureinput:
output:Operating Altitude: 3000 metersinput:
output:The locationinput:
output:A horizontal, flat, clean, and dry surface with a front surface that is at leastAway from direct sunlight, mechanical vibration, and strong electromagnetic interferences, 10 cm inside the table edge.input:
output:Storage Conditionsinput:
output:Temperature range: -10°C to 50°Cinput:
output:Humidity: 85%
