Flow Testing System

A comprehensive, handheld system that is capable of testing nearly all types of ventilators, including adult, pediatric, anesthesia, neonatal, and high-frequency models. It is also capable of testing a diverse array of other medical equipment, including anesthesia gas delivery machines, air oxygen blenders, medical insufflators, oxygen concentrators, and CPAPs.

Details of the Product
The Certifier™ Plus Test System 4080-S comprises a Certifier™ Plus Interface Module 4089 and a Certifier™ Plus High-Flow Module Kit 4081. This multifunctional pneumatic test system is capable of measuring 28 distinct test parameters and displaying the data in real-time visualization. Bi-directional flow sensors that are compensated for pressure and temperature provide gas flow measurements with a high degree of accuracy, a rapid response time, and an industry-leading low pressure drop. Users have the option to measure breath rates up to 1500 bpm using STP, ATP, BTPS, BTPD, or user-defined gas conditions.

The Certifier™ System 4080-S is supplied with a standard kit of accessories, which includes a protective cover, carrying case, rechargeable Li-ion battery (installed), silicone tubing, flow module cable, power supply with plug set, and an inlet filter, airway pressure fitting, and three adapters.

4080-S Test ParametersPeak flow, minimum flow, and flow rate
Minute Volume, Inhaled and Exhaled Tidal Volumes
Low Pressure (Differential)Minimum, PEEP, and Peak Pressures
High Pressure, Barometric Pressure, Plateau Pressure, Static Compliance, Inspiratory and Expiratory Times, Inspiratory Pause Time, and Inspiratory Rise Time are all components of the mean airway pressure.I:E Ratio, I:E Ratio Includes Pause Time
Respiratory Rate
Temperature of GasesOxygen Concentration (with optional Oxygen Sensor Kit 4073)
