Flow Cytometer

► compact and powerfulinput:
output:► Outfitted with a single laser and four filtersinput:
output:► Intelligent analysis, one-button operationinput:
output:► Absolute counting platform with a double assay► Automated self-cleaning for effortless convenienceinput:
output:► Automatic optical parameter setting that eliminates the necessity for manual adjustmentinput:
output:2. The optical system’s overall temperature control, a fixed optical path without adjustment, and a spatial three-dimensional excitation mode;3. Design of linear optical paths, and the substitution of optical filters with experimental requirements;4. In order to enhance the efficiency of photoelectric conversion, the instrument is equipped with an avalanche photodiode (APD).Analytical Performance:1. Fluorescence sensitivity: FITC≤200MESF, PE≤100MESF;2. Fluorescence Linearity: ≥0.98;3. Instrument detection resolution (full peak width CV of forward angle scattered light and fluorescence channel): FSC≤2.0%; FL1(FITC) ≤2.0%; FL2(PE)≤2.0%;4. Resolution of lateral angle scattered light and forward angle scattered light: capable of delineating the three groups of white blood cells (lymphocytes, monocytes, and granulocytes) in peripheral blood; capable of separating red blood cells and platelets in peripheral blood.

5. Forward angle scattered light detection sensitivity: ≤1.0 μm;
6. The flow chamber sample needle can be automatically cleaned to prevent cross contamination after each test is completed, provided that the test carrying contamination rate is ≤0.5%.input:
output:7. The highest event rate is ≤50000 cells per second.8. Absolute counting compatible with the volume method and the microsphere method;Loading System Example:1. Load the sample using a syringe.2. Compatibility with a diverse array of flow cytometry tubes and centrifuge tubes;
