Flow Analyzer

AMI Codes-II O3 is a low-maintenance, proven monitor that is suitable for the measurement of trace concentrations of ozone in water in pharmaceutical applications, down to 1 ppb. The robust colorimetric standard measurement method (DPD) in accordance with DIN 38404-3 is the optimal method for validating the continuous protection of water storage systems against microbial growth and the absence of ozone prior to their use in a pharmaceutical production process.input:
output:Characteristics

All ozone-sanitized water storage systems are compatible with a measurement range of 0-500 ppb.
Reliable results are achieved even in the absence of ozone for an extended period, with no sensitivity loss.

Guaranteed long-term stability by incorporating automatic zero point detection into each measurement.

Simple verification of instrument performance with a filter set; factory calibratedThe integrity of the measured data is guaranteed by the continuous monitoring of the sample flow.input:
output:Rapid plant integration is facilitated by the straightforward process of instrument set-up and qualification.Time is saved by the absence of running-in time following maintenance and the ease of maintenance.Protect your production facilities from contamination with ozone-containing water with confidence.Maximize instrument availability to prevent production interruptions.Keywords: Ozone sanitization, water for pharmaceutical purposes, purified water (PW), highly purified water (HPW), water for injection (WFI), water distribution and storage, on-line measurementinput:
output:Technical SpecificationsOzone measurement -

Range of measurement: 0 to 500 ppbAccuracy - ±1 ppb or 5% (whichever is greater)Minimum detection limit: 1 ppbCycle time: 5 to 10 minutes (default: 6 seconds)
