Floor-Standing Laboratory Chiller

Temperature range: -20°C to room temperature

Utilizes PID temperature control with a built-in PT1000 temperature sensor to ensure precise temperature regulation.A crystal-clear LED display that alternates between the display of the set temperature and the actual temperature.The entire unit is capable of safeguarding against overload, overcurrent, short circuit, and delayed start.Easy drainage is facilitated by the integrated design of the drain outlet and water outlet.The compressor utilizes the cutting-edge R290 refrigerant, which is environmentally friendly.The liquid pathway is constructed from high-quality corrosion-resistant material or stainless steel.A user-friendly operating panel that facilitates operation
Easy filling and cold trap experiments are facilitated by a large-volume open reservoir.Temperature control range: -20°C to room temperature.Accuracy of temperature adjustment: 0.1°CAccuracy of temperature control: ±0.3°C (0°C is a typical value, as is 20°C)Reservoir capacity: 4.5 litersTemperature adjustment range: -30°C to 30°CLED temperature displayTemperature sensor: PT1000Compressor refrigerant: R290 Circulating pump throughput: 22L/minCirculating pump head: 6 metersPump pressure: 0.3 barPump suction: 0.2 bar700 watts of powerThe maximum overall dimensions are 220*420*495 (mm).

Weight: 30 kilograms

110V/60Hz power supplyOperating environment: 10°C to 0°C, with a relative humidity of 80% or higher.
