Fetal Doppler

Opening Statement

The CONTEC10CL Pocket Fetal Doppler is a hand-held device that detects fetal heart rate and employs Doppler technology in its design. The LCD screen displays the waveform and measured FHR value. It is suitable for daily self-checks by pregnant women in hospitals, clinics, and homes, enabling early monitoring and lifelong care. Its operation is both simple and convenient.>

Function• Ease of operation, attractive appearance

The magnetic probe is compact and user-friendly.

Digits/Curve display

– Battery level indication

Automatic shutdown occurs after a 60-second period of inactivity.Fetal heart sounds can be clearly detected for pregnancy periods exceeding 12 weeks with a high-sensitivity Doppler probe.External headphone interface and internal speakerPerformanceType CF applied part safety classification: internally powered equipment- Display: 1.77 inches – LCD screenFHR measurement and display range: 50 BPM to 240 BPM (BPM: beats per minute)- Resolution: 1 BPM

Accuracy: ± 2 BPMDC3 V is the rated working voltage.

3.7V lithium battery type

– Enclosure protection class: IP22InvestigateNominal Frequency: 3.0 MHz- Working Frequency: 3.0 MHz ± 10

– Negative Peak Sound Pressure: p_ ＜ 1 MPa

– Output Beam Intensity: Iob – 20 mW/cm2

spatial-peak temporal-average Derived Intensity: Ispta ＜ 100 mW/cm2

– Ultrasonic Output Power: P – 20 mW

– Continuous wave Doppler operation mode

Transducer With an Effective Radiating Area of No More Than 208 mm2>

AccessoriesOne user manualPhysical characteristics include:◆Dimensions: 157mm (L) × 106mm (W) × 34mm (H)Weight: approximately 300 grams (including batteries)
