Esophageal Sphincter Stimulation Lead

The transesophageal stimulation and recording of proximal cardiac potentials of the atrium and ventricle are achieved through the use of the temporary esophageal leads TO-F and TO-F J, the esophagus stimulator OSYPKA PACE50E, and the Rostock Filter (Butterworth high pass filter). They are appropriate for a diverse array of semi-invasive procedures, including:input:
output:
diagnosis of cardiac arrhythmias in both children and adults

- the precise determination of AV and/or VV delays to support left ventricular
lead implantation during biventricular pacing (CRT)- the stimulation of the left atrium and the representation of the esophagus during
pulmonary vein ablationinput:
output:TO-F (Art. No. 27514)7F in diameter

Number of Poles: 4

Pole Distance: 15-15-15

Lead Length: 95 cm TO-F J (Art. No. 27515)Diameter: 6 centimeters

Number of Poles: 4
Pole Distance: 10-10-10

Lead Length: 95 cm Connection Cable:

- 2-polar, single-use (Art. No. 81827)

- 4-polar, reusable (Art. No. 81826)
