Enteral Feeding Pump

1. The pump is capable of providing continuous feeding.2. Rate: 1-400 ml/h;3. A variety of alarm functions;4. IV set: universal.input:
output:Maximum volume1-9999 milliliters

Precision

±10%

Electricity supplyAC100-240V, 50/60 Hz

Battery1650mAh rechargable lithium polymer battery with a voltage of 7.4 VThere is a maximum consumption of 25VA, which can be used continuously for over five hours after being fully recharged.

Recharge the battery.The battery will automatically recharge when the pump is connected to AC power.(8-14 hours to achieve complete recharge).

Fuse220V 2A×2, 12V 2A×2

Information that has been displayedFlow rate, volume limit, accumulated volume, power supply indicator, and bed number.An alarm function is available.Infusion completion, low battery, control abnormality, and absence of AC supply alarm.

The maximum size of the outer shell is 120×140×190 mm in length, width, and height. The maximum weight is 2.5 kg.Classification: Type B Outer shell material: ABS plastic

Operating conditions:

Environment temperature: 5-40, air pressure: 86-106kPa, and relative humidity: 20%-80%.

Storage conditions include a relative humidity of 20% to 80%, an ambient temperature of -15 to 50°F, and an air pressure of 86-106kPa.

Infusion sets that are applicable include all standard infusion sets.

Adhere to EN ISO 14971:2000, IEC 60601-1:1995, EN IEC 60601-1-2:2001, IEC 60601-2-24, EN ISO 14155-1:2003, and EN 980:2003.EN 1041:1998, MDD 93/42 EEC standard.
