Endoscopy Video Processor

The Endoso 4K endoscope camera system comprises a 4K video processor, a 4K camera head, an LED light source, a 4K medical monitor, a medical trolley, and a rigid endoscope.4K video processor

4K imaging chain@60fps, BT.2020 wide color gamut, customized configuration for different discipline application, 12-bit color depth

4K one-click recording

Ultra-high-definition resolution of 3840*2160P, full-screen horizontal resolution above 1800 lines

Rich 4K output interface (12G-SDI, HDMI 2.0, 3G-SGI, DVI)
Five distinct digital algorithms will be demonstrated, including detail enhancement, dark area improvement, highlight suppression, moiré expulsion, and high dynamic range.4K camera head – Standard camera head and auto focus camera head both available – Camera waterproof performance IPX7Universal C-mount

The standard camera head is capable of supporting seven distinct configurations, including intraoperative photography, video recording, and screen freezing, with a single click.

The auto focus camera head includes an additional auto focus function.Light emitting diode (LED6500K color temperature1800 lm luminous fluxbr/>
Featuring a total of 10 adjustable brightness levelsThe unit’s noise level is less than 50 dB.with a service life of over 60,000 hours, memory functionMedical Monitor
– 32″ x 55″ widescreen LCD display with a 16:9 aspect ratio- Full-color Ultra HD resolution of 3840×2160

High-brightness LED backlighting with consistent output

Viewing angle: horizontal 178°/vertical 178°

Easily cleanable design with a sealed screen (IPX5)The Rigid Scope Portfolio• High resolution, distortion-free • Large depth of field (3-200mm)Laparoscopes

Arthroscopes

Hysteroscopes

– Ergonomic anti-tipping design – Ultra-quiet universal wheel for easy mobility – Medical trolley• Storage drawer at the bottom Convenient access to consumables
