Operating Table Handle
| Applications | Operating Table |
| Material | Stainless Steel |
| Applications | For Endoscopes, Medical |
| Other Characteristics | With Video Processor |
| Resolution Level | Full Hd, Hd |
Product review
Catalog record
Inquiry support
Product summary
Megamedical ENT Endoscopy Visual System VS-DUALFeatures:• Auto-Change Channel System• Auto White Balance (AWB) Function• MWB (Manual White Balance) Mode• IRIS 21 STEPS• AGC (Auto Gain Control) Function (on/off/up)• SHARP 10 Steps• 11 Steps for DNR (Digital Noise Reduction)• Black Ten Steps• HUE 10 Steps• LUXSEN Function (on/off)• Specifications of USB MemoryImage Sensor FHD: 1/3" CMOS FHD HD: 1/3" CMOS HDProgressive Scan is the scan type.
Image Resolution Full-HD resolution: 1,920 x 1,080 pixels High Definition: 1,280 x 720 pixelsAVI Capture Mode - 1, 2, 4, and
Aspect Ratio: 16:9Resolution (H)
FHD: 1000TVL
HD: 800TVL
Video Output - HDMI (2 ports)
Voltage: 220 voltsPower Consumption - 120VA Frequency - 50/60HzWeight Main Body: Approximately 6.5 kg Camera: Approximately 300 grams Dimensions: Main Body: 325mm (L) x 373mm (D) x 150mm (H) ± 10%Camera Dimensions: 55mm (W) x 120mm (D) x 55mm (H) ± 10%
Standard Accessories
Camera (FHD / HD) 2
Foot Switch 1
Light Guide 1
Video Cable 1
S-Video Cable 1
Power Cord 1
Optional Accessories
Medical Monitor
Monitor Holder
Customized Shelf
Cart
Camera Holder
Endoscope
Image Resolution Full-HD resolution: 1,920 x 1,080 pixels High Definition: 1,280 x 720 pixelsAVI Capture Mode - 1, 2, 4, and
Aspect Ratio: 16:9Resolution (H)
FHD: 1000TVL
HD: 800TVL
Video Output - HDMI (2 ports)
Voltage: 220 voltsPower Consumption - 120VA Frequency - 50/60HzWeight Main Body: Approximately 6.5 kg Camera: Approximately 300 grams Dimensions: Main Body: 325mm (L) x 373mm (D) x 150mm (H) ± 10%Camera Dimensions: 55mm (W) x 120mm (D) x 55mm (H) ± 10%
Standard Accessories
Camera (FHD / HD) 2
Foot Switch 1
Light Guide 1
Video Cable 1
S-Video Cable 1
Power Cord 1
Optional Accessories
Medical Monitor
Monitor Holder
Customized Shelf
Cart
Camera Holder
Endoscope
