Electrosurgical Unit Footswitch
Reference: 867268
Surgical Instruments
| Other Characteristics | Single, Double |
| Product Applications | For Electrosurgical Units, For Operating Tables |
| Operation | Electric |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
* Foot switch with a rocker arm* High mechanical stability br/>
* Zinc metal die cast body
Details:Operating Frequency: 60 operations per minuteInsulation Resistance: >100MΩ @500V DC
Initial Contact Resistance: <25 mΩRated Current/Voltage: 10A/15A 1/2HP 250VACInrush Current: AC15/DC13 in accordance with IEC947-5-1
Dielectric Strength: 1000 VAC for 1 minute between current-carrying components
2500 VAC for 1 minute between non-current-carrying components
Service life: 1,000,000 operationsOperating Temperature: -30℃ to +80℃ (-22℉ to 176℉)Protection Level: IPX8 (NEMA 4, 4X, 6, 6P)
* Zinc metal die cast body
Details:Operating Frequency: 60 operations per minuteInsulation Resistance: >100MΩ @500V DC
Initial Contact Resistance: <25 mΩRated Current/Voltage: 10A/15A 1/2HP 250VACInrush Current: AC15/DC13 in accordance with IEC947-5-1
Dielectric Strength: 1000 VAC for 1 minute between current-carrying components
2500 VAC for 1 minute between non-current-carrying components
Service life: 1,000,000 operationsOperating Temperature: -30℃ to +80℃ (-22℉ to 176℉)Protection Level: IPX8 (NEMA 4, 4X, 6, 6P)
