Electroretinograph With Evoked Potential Monitoring

Advanced flash capabilities• The luminance range of ColorDome™ is trillions-to-one.• Flash duration ranging from nanoseconds to hours• Any color background from RGB and amber LEDsUltimate performance, effortless operation• Self-calibrating• Complete electronic color control• Stimuli that flash or flicker in any color and for any duration• Applications br/>


Multiple desktop and cart mount options• Disease diagnostics and monitoring• Research and development• Drug discovery and screening• Clinical trials• Neuro-ophthalmology



LED flash
Any color flash is available, including RGB and amber LEDs, as well as UV LEDs.Red (627 nm), Amber (590 nm), Green (530 nm), Blue (448 nm)The luminance range of LED sets is 9 orders of magnitude.Flash duration ranges from nanoseconds to hours.Ultra-stable luminance and color output is achieved through proprietary CIE compensation.The maximum white flash is greater than 60 cd·s/m2 (6 times the maximum flash allowed by the ISCEV standard).

Waveforms such as sine and exponential, on/off flashes of any duration, and an arbitrary wavetable are all possible.

Calibrated in Trolands, photopic, and scotopic units

Color and luminance stimuli that are defined by the userSelf-calibrationinput:
output:Xenon flashThe Xenon flash was calibrated on a scale of 0.001 cd·s/m2 to 2,000 cd·s/m2.

Triple tube for linearity and a broad range

The flash duration is adjusted in real-time by auto calibration, which monitors each flash.
Integral filter holder for the addition of customer filters as needed.The maximum white flash is 2,000 cd·s/m2.Calibrated in Trolands, photopic, and scotopic units

Capable of double flashes, including the "double bright flash" protocol.In general, the flash

The flash luminance ranges from 10-8 to 2,000 cd·s/m2.Luminance can be adjusted with a resolution of at least 1% within this range.
