Electronic Moisture Balance

Precision of the thermo balance The moisture content of the products is determined using a halogen lamp. A graphic representation that includes the weight, dry and wet product, drying time, and temperature. input:
output:Technical specifications:• LCD graphic display featuring the following information: weight, temperature, drying time, dry, and wet.

• Stainless steel heater.

•Heated by a halogen lamp.

• PT100 temperature sensor.

• Temperature control, with an LCD display that displays the reading.

• A temperature scale ranging from +50° to +160° – with a division of 1 °C.

• The minimum dry substance is 0.5 g.

• External calibration.
• Calibration weight is included.

• Select a timing range of 1 to 99 minutes.

• RS232 interface.

• Auto-Stop feature.

• A humidity scale with a division of 0.01%, ranging from 0 to 100%.

• Dry reading from 100% to 0.01%.

• An acoustic alarm will sound at the conclusion of the drying and storage process, and the value will be displayed.

• The capacity to conduct the test again without the need to reset the temperature and time data.

• Aluminium pan, 0100 mm in size.

• Power supply: 0.4 kW, 220 V phase, 50 Hz.

• Leveling feet and air bubbles.

• Net weight: 3.0 kg. Dimensions: 285 mm x 60 mm x 50 mm (H)input:
output:
A precision halogen lamp thermometer with a microprocessor system is utilized to ascertain the moisture content of the products. Halogen lamp for high reliability during extended operation. Oven with stainless steel cladding.input:
output:Technical specifications:

• LCD display with backlight.

• Stainless steel heater. Utilizing a halogen lamp for heating.

• PT100 temperature sensor.

• Digital readout for temperature regulation via microprocessor

• A temperature scale with a division of 1 °C, ranging from + 35° to + 160°.

• A minimum of 3 g of dry substance is required.

• External calibration. Calibration weight is included.

• Filters that are electronic.

• Capacity to retain five programs.
