Electronic Filling Machine

The Capsule Filling Machines in this series are equipped with a touch screen panel, electronic automatic counter, speed-shift, and programmable control system.

It is capable of performing the actions of positioning, separating, filling, and locking capsules in a fully automatic manner. The reliable interchangeability of various capsule models is ensured by the use of advanced high-precision CNC tooling machines to machine all models.

It is appropriate for a variety of products, including conventional pharmaceuticals such as powder, pellets, and granules, as well as nutriceuticals such as herbs, vitamins, and special products with fibrous, abrasive, or sticky properties. A straightforward operation, format changeover, and dosage accuracy are all provided by this space-saving machine.input:
output:
Principal Technical Parameters



Number of die orifices: 4 6 9

Vacuum: 27 m³/h -0.02～0.08Mpa

Capsule number: 00-5

Filling percentage: ≥99.9 percent

Summing the discrepancy: ±3

dB(A) idle load noise: ＜70

Power of the machine: 3 kW at 380V and 50Hz.
