Electric Mucus Suction Pump

• Piston pump that requires no maintenance

• Nominal suction power: 800 mbar (80 kPa) ±10%

• Free-cycle maximum operating time: 60 minutes ± 10%

• Lithium polymer battery of the inorganic solid type

• IP44 rating for protection against liquid and solid infiltration

• Charging/functioning: 11-30 VDC

• Autoclavable collection jar OB-J FA 1000 ml with overflow valve and protective filter inserted directly into the lid, autoclavable for a maximum of 30 cycles

• The ability to monitor the battery charge status without the need to activate the device. The user has the ability to remove and replace the battery.

• The OB 3000 suction unit is equipped with an internal microprocessor control that enables the storage of device construction and operating data.

• The user is notified of the necessity for scheduled device maintenance by a unique feature.

• A fluorescent analogue vacuum gauge is available for use in low-light conditions and can also be equipped with a mmHg (millimeter of mercury) scale upon request.• Comes with a recharging cable that includes a 2-pole connector and a cigarette lighter plug.• Optional: The suction unit may be equipped with an OB WB charging bracket (in compliance with EN 1789) and an external mains-voltage power supply with a 2-pole plug (mains power supply between 100 and 240 Vac).

• In accordance with the primary reference standards, Directive 93/42/EEC, and all relevant regulations
