Electric Mobility Scooter
Reference: 575475Mobility Aid
| Number Of Wheels | 3-Wheel |
| Options | With Basket |
| Propulsion | Electric |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
The most substantial component during disassembly
Weight: 30 lbs / 14 kg
Features: Swivel Seat, Flat-Free Solid Tire
Autopower Connection: Drop & Drive
On-board/DFF-board charge is available.
Optional features include a pull-type handlebar and a fish-on seat.
SpecificationsWeight with battery: 43.2 kg Weight without battery: 35 kg Dimensions (L x W x H inch): 35.8" ×18.7" ×35.8"Battery - 12 AH × 2Controller: CTE SATAR series Front Wheel Size: 6" × 2" Rear Wheel Size: 6" × 1.5"/8"Electromagnetic brakes comprise the brake system.Control Method - Utilizing a speed control leverThe maximum forward speed is 6.4 km/h (4 mph). The maximum load is 250 lbs.Drive System - The rear wheels are directly driven.motor specifications: 270 watts at 4700 revolutions per minute, one unit.Type of Frame Construction and Materials: Aluminum Type of Battery Charger:and Input Voltage - off-boardDC 24V, 1.5 ANA - Suspension
Safety Features - Anti-tip wheelThe device is intended for use in the following locations: pavement, single carriageway, and pedestrian area.
Weight: 30 lbs / 14 kg
Features: Swivel Seat, Flat-Free Solid Tire
Autopower Connection: Drop & Drive
On-board/DFF-board charge is available.
Optional features include a pull-type handlebar and a fish-on seat.
SpecificationsWeight with battery: 43.2 kg Weight without battery: 35 kg Dimensions (L x W x H inch): 35.8" ×18.7" ×35.8"Battery - 12 AH × 2Controller: CTE SATAR series Front Wheel Size: 6" × 2" Rear Wheel Size: 6" × 1.5"/8"Electromagnetic brakes comprise the brake system.Control Method - Utilizing a speed control leverThe maximum forward speed is 6.4 km/h (4 mph). The maximum load is 250 lbs.Drive System - The rear wheels are directly driven.motor specifications: 270 watts at 4700 revolutions per minute, one unit.Type of Frame Construction and Materials: Aluminum Type of Battery Charger:and Input Voltage - off-boardDC 24V, 1.5 ANA - Suspension
Safety Features - Anti-tip wheelThe device is intended for use in the following locations: pavement, single carriageway, and pedestrian area.
