Electric Cast Saw

Reference: 420043Orthopedic Surgery
Power SourceElectric
AccessoriesWith Vacuum Cleaner

Associated tags

manage_search

Product fit review

Compare the available product information with your application and purchasing requirements.

description

Documentation request

Ask which specifications, manuals, or commercial documents are available for review.

support_agent

Supplier coordination

Discuss quantity, destination, packaging, and timing before confirming suitability.

Product information

Product summary

The CC4 cast saw's 110 watt motor ensures that even the thickest body casts are cut quickly and efficiently.input:
output:Characteristics:The operator is granted exceptional control and mobility due to the knurled grip that is situated in close proximity to the saw blade.input:
output:A clear extraction hood is available as an option to guarantee optimal visibility during the cutting process. The hood is fully rotatable to accommodate the most convenient cutting position.
Extractor:
The CleanCastâ„¢ extractor is equipped with a four-stage filtration system that includes a synthetic collection bag that is effortless to replace, two cloth filters, and a micro filter.input:
output:The Hepa-flo microfilter provides a safe working environment for all by retaining 99.997% of all dust particles greater than 0.5 microns.input:
output:To accommodate the operator and patient's preferences, the suction rate can be adjusted between the quiet "low" and the powerful "high" setting.input:
output:Technical Details:HandpieceSpeed of oscillation: 14,000 (or 16,000) cpm

The voltage is either 230 Vac or 120 Vac.

Weight: 1,300 grams

Sound intensity: 70 decibels (A)

Length: 333 mmExtractorMaximum power of the motor: 1 kW.Voltage of supply: 240 volts or 100-120 volts

Frequency of supply: 50-60 HzSuction: 2,500 mm of water gaugeFiltration: 99.997% > 0.5 microns

Dust bag capacity: 7.5 litersSound intensity: 58 decibels (A)
