Electric Blood Donor Chair

Chair dimensions: 1700mm x 560mm x 10mm.Chair height: minimum 540mm±15mm,highest 830mm±15mm (excluding the cushion)

Head section turning angle: ±15°Turning angle of the back section: 0° to 80°Seat section tilt angle: 0° to 12°Leg section turning angle: 0° to 90°Swing out of the arm board: 0° to 45°Arm board slide: 100mmArm board height adjustment: 100mm

Loading: 160 kgNet weight: 130 kilogramsinput:
output:Methods of operationThe device is equipped with a "adjustment spanner" that is used to secure or unlock the base. The base can be locked by rotating the support feet clockwise, while it can be released by rotating them anticlockwise.Utilizing the hand control.The operator is required to activate the appropriate operation by pressing the icon on the "hand control" in accordance with the specifications. When the back section is raised, the armrest is also raised; conversely, they are simultaneously lowered. The armrest is consistently maintained in a horizontal position.The structure of the armrest is knock-down. Any side of the armrest may be employed by the user in accordance with the actual space available for placement.Armrest disassembly,Raise the armrest by 90 degrees from its default position. In this position, grasp the round pipe at the rear end of the armrest with one hand and the front end of the armrest with the other hand. Then, pull out.
