Ecg Simulator

Phantom 320 is specifically engineered to meet the operational requirements of the medical industry, offering a variety of pathological and normal signals, as well as varying heart rate values. Additionally, a cyclical sequence of all available signal types is released to facilitate testing.input:
output:Technical characteristics:A maximum of 32 waveforms exhibiting either normal or pathological signs.

Simulation of: 8 synusal rhythms, 7 outrentricular speed, 9 ventricular arrhythmias, and 3 pacemakers

The cyclic mission is automatically programmed for a duration of approximately 17 minutes, utilizing all available signals.

Twelve derivatives I, II, III, AVR, AVL, AVF, V1, V2, V3, V4, V5, V6, and 14 banana connections 4 mm and snap, with identification and coloration in accordance with DIN EN 60601-2-51

8-bit resolution, 256 Hz sampling frequency, and a bandwidth of 0-120 Hz.

20 ohms as the impedance to the electrodes, and 100 ohms as the impedance at the 1V exit.input:
output:Waveforms:Eight sinuses (QRS normal) 30, 45, 60, 75, 90, 120, 150, and 180 beats per minute

Seven rhythms of bituminous material

Nine ventricular arrhythmiasThree pacemakers2 ST (over-and sub-capping) changesST flat, bottom-up, and top-downBradycardiaTachycardia

ECG with artifactsECG with network interference at 50/60 HzThe duration of the FP, QRS, and RR is contingent upon the RR (following Lepeschekin).Power supply:2 x 1.5-V LR 6

Continuous operation for an estimated 100 hours of autonomy

audible alarm at the critical charge levelinput:
output:Environment:Operating temperature: 0°C to 40°CStorage temperature: -20°C to 80°CHumidity: 10% to 90% without condensationPressure: 700/1,500 hPainput:
output:Dimensions: 150 x 100 x 40 mmBatteries included, the weight is 400 g.
