Ecg Module For Multi-Parameter Monitor

It is appropriate for use in medical institutions and hospitals, but it is not suitable for patient monitoring due to the absence of an alarm function.input:
output:Functioninput:
output:Characteristic

High-speed transmission via USB.input:
output:ECG

At any point during the collection process, the ECG waveform may be displayed and printed.

Multi-lead overlay analysis allows for the selection of any lead for analysis, resulting in a more precise search of the QRS wave.

The histogram analysis function, interval, interval ratio, voltage, QRS width, QRS area, and HR histogram can be selected for analysis.

Analysis function for scatter plots, including density and mixed scatter plots.

The atrial fibrillation analysis function employs a combination of time scatter plot and Lorenz scatter plot to display the location of the atrial fibrillation event, making it easy to position for diagnosis.Nigerian Institute of Business and Politics

Utilizing the capabilities of automatic cycling blood pressure measurement for 24 hours and the establishment of a measurement interval.

Functions for reviewing and printing BP data.

Systolic, diastolic, and mean pressure measurements.SpO2 is the oxygen saturation level.

Review and print functions for SpO2 trend charts.input:
output:Application fields:Applied in the field of dynamic ECG examination to collect and store patient's physiological parameters (12-lead ECG, BP, SpO2 (optional), etc.) for a minimum of 24 hours, analyze dynamic ECG and dynamic BP using the analysis software, capture paroxysmal and occult arrhythmias, diagnose ischemic heart disease, and evaluate the clinical effect of pacemakers, among other things.
