Duct Fan Coil Unit

The 35E unit is one of the most adaptable single-duct products available, boasting a compact design and a variety of control packages. The 35E single duct unit is capable of meeting the majority of application requirements by providing either cooling alone or cooling with reheat. The unit is engineered to provide the highest degree of flexibility in terms of control and configuration. The unit's diminutive size guarantees that it will effortlessly accommodate the majority of applications.input:
output:Performance Characteristicsinput:
output:Airflow capacities range from 75 to 5995 m3/h.input:
output:Round inlets with diameters ranging from 4 inches to 16 inches are available.Construction of galvanized steel casinginput:
output:Appropriate for applications with low, medium, or high pressure.A linear, multiple-point, averaging velocity sensor with an amplified signalinput:
output:The damper blade is equipped with a flexible gasket that ensures a secure airflow shutoff.input:
output:The damper blade is capable of operating at a full 90 degrees.input:
output:The Carrier Control Network (CCN) is optional, while the BACnet protocol is standard and pressure independent.input:
output:Field-adjustable fan airflow is enabled by electronic speed control (silicon controlled rectifier [SCR] type).Isolated motor/blower assemblyinput:
output:Reheat coils that are powered by electricity or hot waterinput:
output:Numerous casing liners are accessible.input:
output:Electric heat (1 to 3 stages) or proportional heatFeatures of Reliabilityinput:
output:Heaters that are equipped with:input:
output:Primary automatic and secondary manual reset thermal cutout fuse and positive pressure air flow switchinput:
output:A robust integral post or panel input:
output:Robust panel/post constructioninput:
output:Features of MaintenanceA removable bottom access panel is provided to facilitate routine inspections and maintenance.input:
output:Model, size, airflow (m3/h), balancing chart, and tagging data are all included in the label information that is attached to each unit.
