Dissection Stereo Microscope
Reference: 1055915
Laboratory Medicine
| Type | Optical |
| Microscope Head | Trinocular |
| Ergonomics | Upright |
| Applications | Dissection |
| Configuration | Benchtop |
| Light Source | Led |
| Options And Accessories | Zoom |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
Finite Distance Optical System - OpticsTilting trinocular interpupillary distance adjustment: 54-76mm; diopter adjustment: ±5 diopters Observation tubes
Seidentopf Head, inclined at 45°, serves as the viewing head.Optical Coating - Transmittance ≥ 95%
Eyepiece - WFConvenient for observers who wear glasses; 10X/20mm high-eyepoint, wide-field.*Optional eyepiece15X/15mm, 20X/10mm, 25X/9mm, and 30X/8mmFocusing - Focusing mount with a vertical working distance of 50mm
Standing -Vertical post: 240mm; diameter: φ32mm; with a φ95mm B/W plastic and Perspex plate and paired clips; base size: 200×255×60mmIllumination - LED illumination that is both reflected and transmitted- 1 C-Mount; *0.5 C-Mount; *0.3 C-Mount
Electricity: 100-240V AC, 50/60HzPackage Dimensions (mm) - 510*280*390Gross Weight (kg) - 7*Optional - MSC-ST45T: microscope camera (Standard imaging software) / Win 10 pad / digital displayNotes: Optional eyepieces and objectives are available for the 3.5X-270X scope. - Notes: Optional eyepieces and objectives are available for the 3.5X-270X scope.
*Optional Configuration - *Optional Configuration
Seidentopf Head, inclined at 45°, serves as the viewing head.Optical Coating - Transmittance ≥ 95%
Eyepiece - WFConvenient for observers who wear glasses; 10X/20mm high-eyepoint, wide-field.*Optional eyepiece15X/15mm, 20X/10mm, 25X/9mm, and 30X/8mmFocusing - Focusing mount with a vertical working distance of 50mm
Standing -Vertical post: 240mm; diameter: φ32mm; with a φ95mm B/W plastic and Perspex plate and paired clips; base size: 200×255×60mmIllumination - LED illumination that is both reflected and transmitted- 1 C-Mount; *0.5 C-Mount; *0.3 C-Mount
Electricity: 100-240V AC, 50/60HzPackage Dimensions (mm) - 510*280*390Gross Weight (kg) - 7*Optional - MSC-ST45T: microscope camera (Standard imaging software) / Win 10 pad / digital displayNotes: Optional eyepieces and objectives are available for the 3.5X-270X scope. - Notes: Optional eyepieces and objectives are available for the 3.5X-270X scope.
*Optional Configuration - *Optional Configuration
