Medical equipment sourcing
Disposable Humidification Chamber
Reference: 1133652Intensive Care
| Other Characteristics | Disposable, Infant |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
The mechanism linkage is reduced by a unique structure with a patent in a single suspension-float.
The float, the tube, and the caps are connected by the minimal structure of the central axis.
The auto-feeding chamber ensures that the humidification output is optimized, thereby reducing the need for refilling. Specifications
Feeding: Automatic
Inlet/Outlet (mm): 22M/22M
Compressible volume (ml): greater than 190
Maximum Water Capacity (ml): 80
Resistance (cmH2O/L/S): 0.45 ± 0.1
Compliance (ml/cmH2O): 0.27 ± 0.10
Chassis Diameter (mm): 120
Material: PP, PVC, silicone, and aluminumIV line (cm): 120 ± 1
Weight (g): 100 ± 2
The float, the tube, and the caps are connected by the minimal structure of the central axis.
The auto-feeding chamber ensures that the humidification output is optimized, thereby reducing the need for refilling. Specifications
Feeding: Automatic
Inlet/Outlet (mm): 22M/22M
Compressible volume (ml): greater than 190
Maximum Water Capacity (ml): 80
Resistance (cmH2O/L/S): 0.45 ± 0.1
Compliance (ml/cmH2O): 0.27 ± 0.10
Chassis Diameter (mm): 120
Material: PP, PVC, silicone, and aluminumIV line (cm): 120 ± 1
Weight (g): 100 ± 2
