Disintegration Tester

Temperature prefabrication range: R.T. ⽞50℃

display resolution: 0.1 °C.The temperature control accuracy is ±0.3℃.

One basket setinput:
output:The disintegration time limit tester is a drug test instrument that is designed to evaluate the disintegration time limit of tablets, capsules, and pills in accordance with the Chinese Pharmacopoeia.input:
output:Primary characteristics:

One basket set.

The instrument automatically regulates the bath temperature at 37.0℃ in accordance with the Pharmacopeia. In order to guarantee the highest precision and accuracy of the water bath temperature, a high-precision digital electronic sensor is implemented, eliminating the necessity for calibration.

The lifting time of baskets is automatically set to 15 minutes by the instrument, but it can be reset at any time.

It employs computer control technology that is focused on SCM to intelligently regulate two performance parameters, namely bath temperature and working time.

The instrument is capable of automatically safeguarding itself, providing an over-temperature alarm, and monitoring the temperature of the bath.input:
output:Detailsinput:
output:Temperature prefabrication range: room temperature to 50°C

0.1℃ is the display resolution.

Accuracy of temperature control: ±0.3℃

Prefabrication timing range: 1 minute to 900 minutes.Accuracy of time control: ±0.5 minutesWork noise: 60 decibelsOne set of lifting baskets is required.Basket lifting frequency: 30 to 32 times per minute.Basket lift distance: (55±1) mmThe minimum spacing from the screen to the bottom of the beaker is approximately 25mm, with a tolerance of 2mm.Standard configuration: 2mm mesh size, with the option of optional 0.425mm and 1mm bore diameters.220V, 50Hz power supply

total power: 600 wattsDimensions: 260mm x 300mm x 440mm
