Digital Phoropter

Enhancing Dependability

Every test is executed with lightning-fast precision.1. Dual cross-cylinder lensOffers a dual cross cylinder lens that is 30% faster, faster, and more precise for astigmatic testing, allowing for rapid and convenient measurement.input:
output:2. Interconnection of a variety of chart devicesinput:
output:The HDR-7100P seamlessly integrates with a variety of chart devices, providing both wired and wireless connectivity options, including LCD charts, dream charts, and projectors.input:
output:3. Touchscreeninput:
output:An intuitive guide is provided by the touch screen interface, which guarantees user-friendly and convenient operation.input:
output:4. Guide to real-time optometryinput:
output:The HDR-7100P offers real-time guidance through the test process by displaying graphical representations on the screen.input:
output:1. Range of Measurementinput:
output:Spherical Lens -29.00 ~ +26.75D (Regular)-19.00 ~ +16.75D (During XC or prism tests)

(0.12/0.25/0.5/1/2/3/4D increments)

Cylinder Lens 0.00 ~ ±8.75D (0.25/0.5/1/2/3D increments)

Cylinder Axis 0˚~ 180˚ (1/ 5/ 15˚ increments)

PD 48 ~ 80mm (0.5/1mm increments)

Near PD: 50 to 74mmWorking Distance: 35 to 70 centimetersRotary Prism Lens 0 ~ 20△ (0.1/0.2/0.5/1/2△ increments)

Cross Cylinder ±0.25D

±0.50D

Retinoscopic Lens +1.5D, +2.0D (Measurement Distance 67cm, 50cm)
±0.25D prism split lens (Dual Cross Cylinder)2. auxiliary lenses



Pinhole lens ø2mm

Maddox Rod Right Eye (Red, Horizontal), Left Eye (Red, Vertical)

Red/Green Filter Left eye (Green), right eye (Red)Polarizing Filter: Right Eye (135˚, 45˚), Left Eye (45˚, 135˚) Split (dissociation) Prism: Right Eye (6△ BU) Left Eye (10△ BI: up to 5△ complement)Fixed XC Lens (±0.50D, with the axis fixed at 90˚)Visual Field 40° (VD=12mm)
