Digital Moisture Analyzer

The AQUATRACE® easyLINE is a new, P2O5 trace moisture analyzer that is particularly affordable and capable of measuring ppmV | ppbV for inert and combustible gases. It features an integrated sampling system. The system measures the volume-related moisture content in the gas and outputs it as ppmV. Additionally, it approximates the value into the corresponding dew point temperature. The measuring system is also equipped with limit alarm relays and status relays, rendering it suitable for industrial and process moisture measurement. The measured value is represented on the 1.8" TFT display. The display color transitions to flashing red if the range is either exceeded or not reached. The analyzer is equipped with an RS232 interface, which can be utilized to read out the measured value and to adjust to local conditions, in addition to an analogue output of 4-20mA.



Particularly well-suited for the following industries:Insulators and glove boxesVacuum technologyPlasma, sintering, and soldering furnacesTechnologies that utilize protective gases, such as thermal treatments, welding, and soldering, are included.input:
output:Plant coatingAdditional benefits of our established P2O5 trace moisture measurement method include:input:
output:Integrated sampling system with rotameter (standard calibration for air)The measurement results are not subject to drift.Sensor element that is both durable and robustThe measurement results are not subject to drift.Maintenance-friendly, there are no additional expenses.input:
output:Offset | Span | Bases are feasible through a digital interface.input:
output:Wet to dry: T90 < 15 min; dry to wet: T90 < 5 secinput:
output:A significantly higher resolution is achieved with 0.01 ppmV in the range of 0-500 ppmV and 1 ppbV in the range of 0-20,000 ppbV.input:
output:Digital communication and analogue output are accomplished through the use of RS232.input:
output:Limit and status relays1.8" TFT displayVersion EX(i) is available upon request.
