Digital Microscope

The VW series is equipped with two types of LED lights that can be toggled between white and UV light. This model is equipped with a filter that effectively eliminates the UV light that is reflected back, thereby enabling the acquisition of an image with authentic colors. The aluminum housing provides superior protection and durability, as well as the most appealing appearance and texture.

Total number of LEDs = 4 + 4
LED on/off switchable: - YesInfrared filter - IR cut-filter >650 nmNo diffuser is available.Emission filter: Yes, UV cut filterPolarizer - AbsentOpticsMagnification: 10-70x, 200xMacro zoom is not available.Standard working distanceSensor
Lens type: Glass with an anti-reflection coatingCMOS sensor typeResolution: 1.3 Megapixel (1280x1024)Maximum frame rate: 30 frames per second Compatibility:Interface: USB 2.0Operating system: Windows 7, 8, 10, and 11, as well as MacOS 10.9 and later.Software included: DinoCapture 2.0 (Windows) and DinoXcope (Mac OS).Image formats that are supported on Windows include BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, and PGX.Video formats that are supported on Windows include WMV, FLV, and SWF.Images in the following formats are supported on Mac OS: JPEG and PNG.(MacOS) Video formats that are supported include MOV.DirectShow and UVC are the imaging standards.Wifi - Wirelessly compatible; an optional WF-10 WiFi streamer is required.HousingThe housing material is metal.Magnification lock is not available.Cable length: 1.8 metersCharacteristicsUnique characteristic - NoMeasurement: YesCalibration: YesMicrotouch sensor: YesYes, it is ESD-safe.DataIncluded in the package are a user manual, calibration target, software CD, carry pouch, and microscope.Warranty information: Two years of European coverage.Regulatory approval: CE, FCC, ROHS
