Dental Laser

Benefits:The CO2 laser provides less tissue trauma and edema, resulting in minimal heat damage and a significantly shorter healing time, due to its higher power and relative efficiency.

CO2 deep heating induces collagen growth and remodeling during ablation, while simultaneously providing the patient with a level of comfort and convenience that is comparable to that of non-ablative resurfacing.

Fractional technology distributes laser energy in an even pattern, resulting in balanced vaporization, coagulation, and thermal effects on the tissues, regardless of whether the user is using a standard skin handle or a gynecology/vaginal handle. These effects induce collagen contraction, which results in a tightening effect that is deemed effective for resurfacing.

The CO2 laser system is able to expand its clinical applications by combining surgical and ENT handles that are based on different handles.

Fractional System:The intensity of the pilot beam can be

Ultra pulse is char-free.

LCD Display ScreenMemory Preservation FunctionAdjustable on-time and off-time

Safety MeasuresReduced bleedingEnhanced bacterial reductionReduced postoperative discomfortWound healing without scarringSpecifications:

Laser Type – Sealed-off: CO2 laser tubeWavelength: 10.6 μmMode Structure: TEM00Range of Power to Tissue: 0.5 to 40 wattsUltra pulse duration (on-time): 10ms to 1000ms Laser operation modes: Continuous wave (CW), pulse, ultra pulseTissue Exposure Modes: Continuous, Single Pulse, Repeat Pulse

Adjustable aiming beam: 2 mW (650nm diode)Articulated Arm: Seven-jointed Articulated ArmLiquid Cooling: Closed Loop

Electrical power: 110/220V, 60/50HzDimensions: 520mm x 440mm x 1470mmSpot size of ceramic tip: 200 um, 400 um, 600 um
