Dental Laboratory Dust Suction Unit

The AS/CAM1 is appropriate for connection to a single milling machine. It is equipped with a 1000 W single phase 230V universal motor that is of the latest generation and does not require the replacement of carbon brushes. It has an average lifespan of approximately 2500 hours.input:
output:The primary sack filter of the unit has a surface area of 7300 cm², while the secondary cartridge filter has a surface area of 3650 cm².input:
output:The combined performance of the two filters is equivalent to grade "H" of filtration as defined by the EN-60335-2-69 standard.input:
output:The air is discharged directly to the atmosphere through a 5 cm pipe, which reduces the air temperature and recycles untreated dust. The activation of suction can be performed manually or automatically upon request, utilizing an interface that is specifically designed for any milling machine. The unit is equipped with a sensor that monitors the status of the filters and activates a red warning light when the filters are full.

Technical feature:· Noise volume: 65 decibels.

· Dimensions: 41x43x71H cm (allow 15 cm of space on the right side for connections).
