Dental Curing Light

Version that is integrated
The ergonomic handpiece can be easily positioned in the quiver (its holder) to incorporate the starlights into a dental unit. Starlight's curing capability includes two modes: "fast" (10 seconds) and "slow rise" (20 seconds with a gradual progression during the initial three seconds).TECHNICAL SPECIFICATIONS
Device that adheres to Directive 93/42/CEE: - Class IIa
Classification in accordance with EN 60601-1: - IIType BF
IP 20 (unit)

- 24 Vac 50/60 HZ is the power supply voltage.Double insulation for a 33 VDC supplyMaximum power absorbed: -9 watts
Fuses - 315 mA T (Not included in the Mectron supply)Intermittent operation device: - 120 seconds of operation, followed by 40 seconds of inactivity
Light source: - High-luminosity LED with opticsDominant wavelength: 440-465 nmLED light emission: greater than 1.400 mW/cm2.The average lifespan is 1,800,000 cycles, with each cycle lasting 20 seconds.Optical fiber: -
8 mm in diameterComposition: Coherent fibers that have been drawn and sufaced in transparent quartz.Autoclave sterilizable (maximum temperature of 135°C for 20 minutes; maximum number of cycles: 500).Exposure: - Rapidly: Duration of exposure: 10 seconds - Acoustic signals that signal the commencement and conclusion of the exposureAcoustic signal at the beginning, after 10 seconds, and at the end of the 20-second exposure time: Slow riseThe cycles can be halted or repeated at any point.Conditions of operation: - between +10°C and +40°CRelative humidity ranges from 30% to 75%.Air pressure (P) is 800 hPa/1060 hPa.Transport and storage conditions: - from -10°C to +70°CRelative humidity ranging from 10% to 90%
Air pressure (P) is 500 hPa/1060 hPa.Sizes and weights: 65 grams L 148 mm, maximum Ø 22 mmDevice warranty: three years
