Delivery Bed

Delivery bed with three sections that can be adjusted in heightinput:
output:electrostatically painted with epoxy powder, heavy-duty metal frame

• Legs that are fully adjustable provide

• ABS is the material used to construct the sleeping surface.• One control unit, three single drives, and one patient handset• Mattress with detachable cover

• Fluid basin• A built-in leg section that can be effortlessly positioned beneath the bed's surface• ABS is utilized for the base and mechanisms cover.

• Four elastic bumpers

• Receptions of IV poles>




MOVEMENTS-FUNCTIONS-DIMENSIONSinput:
output:Trendelenburg 12°Range: 380 mmThe rear section is inclined at a 70° angle.Minimum height: 520-540 mmwith siderails - 1030mm, 950mm, and 860mmOPTIONAL MOVEMENTSAnti-Trendelenburg 6°. Optional. In this instance, the height is elevated by 50 mm.A 25° lift of the pelvic section is recommended.PANELS AND HEAD/FOOT FRAMES

Frames made of plastic with an internal panel Frames made of plastic that lack an internal panel input:
output:BED'S MOVEMENTS ARE FOLLOWED BY SIDERAILS

Side rails composed of plastic that lack an internal panel Side rails made of plastic with an internal panel
