Cube Laboratory Ice Maker

CNS quality, high-grade stainless steel, with a rounded front side, including a covering plate. Galvanized sheet steel is used on the rear side. Access is provided through a high-quality, insulated top panel made of silver-gray plastic that is retractable and adjustable on four sides.input:
output:Ice storage containermade of plastic (ABS-quality). The smooth, easily accessible surfaces and rounded corners make it easy to clean and hygienic. input:
output:Air conditioning unit

The condensing unit is bottom-mounted and is compounded by a Nr. 1 hermetic compressor and a Nr. 1 finned condenser. It is air-cooled by a fan. Furthermore, the motor compartment is equipped with a unique evaporator that is shaped like a cube. Once the cubes have been formed, they are automatically released into the storage bin. In order to ensure the highest level of reliability, all of the components that are mounted are of industrial grade. input:
output:Function:Stock replenishment is automatic and contingent upon demand. If necessary, the cooling aggregate is activated through sensor technology (contactless) and is automatically deactivated when the storage container is reached capacity. High economic efficiency is achieved through the combination of short running times and significant energy savings. input:
output:The safety of the operator and the machine is ensured by the integration of microprocessors of the most recent generation into the switching and control circuits of all critical operating functions.input:
output:The rear of the unit is where the water inlet and outlet pipes are situated.The diameter of the water inflow pipe is 3/4 inches, and its length is 110 cm.

The operator is responsible for providing a hose with a clamp. The water outlet pipe has a diameter of 24 mm and a length of 50 cm.

Installation is feasible in nearly all locations, and operation is effortless due to the extensive collection of physical data necessary for operation.

a. The temperature of the incoming water may range from +5°C to +40°C.
