Corneal Topographer

Is the most sophisticated instrument for the examination of the anterior segment of the eye. MS-39 integrates high-resolution OCT-based anterior segment tomography with Placido disk corneal topography. The anterior segment specialists will appreciate the clarity of the cross-sectional images, which have a 16 mm diameter, as well as the numerous details of the cornea structure and layers that the MS-39 has revealed. MS-39 offers data on the dioptric power, curvature, elevation, and pachymetry of both corneal surfaces.



MS-39 is capable of being employed in corneal surgery for refractive surgery planning, in addition to anterior segment clinical diagnostics. Additionally, an IOL calculation module is accessible, which is predicated on Ray-Tracing methodologies. MS-39 is capable of conducting precise pupil diameter measurements and advanced tear film analysis with the assistance of supplementary tools.



CORNEAL SECTION

The instrument's extraordinary features, including the sharpness of the high-resolution section images on a 16 mm diameter and the numerous details of the structure and cornea layers that are revealed, are greatly appreciated by the specialists of the anterior segment (corneal and epithelial). The device furnishes data on power, curvature, elevation, and pachymetry for both corneal surfaces.



EPITHELIAL AND STROMAL MAP

Advanced measurements of the epithelial and stromal layers are included in MS-39. It is highly beneficial to have an understanding of the morphology of the epithelial masking effect in order to evaluate corneal surface abnormalities. input:
output:CORNEAL ABERROMETRYAberrometric analysis provides a comprehensive examination of corneal aberrations. The contribution of the anterior, posterior, or total cornea can be determined for varying pupil diameters.
